| Server Model | Dell Poweredge R760 Server |
| Processor | Up to two 4th Generation Intel Xeon Scalable processor with up to 56 cores per processor and with optional Intel® QuickAssist Technology |
| Memory | • 32 DDR5 DIMM slots, supports RDIMM 8 TB max, speeds up to 4800 MT/s • Supports registered ECC DDR5 DIMMs only |
| Storage Controllers | • Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i • Internal Boot: Boot Optimized Storage Subsystem(BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB • External HBA (non-RAID): HBA355e • Software RAID: S160 |
| Drive Bays | Front bays: • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 240 TB • Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.64 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB |
| Power Supplies | • 2800 W Titanium / 2400 W Platinum / 1800W Titanium / 1400 W Platinum / 1100 W Titanium / 800 W Platinum / 700 W Titanium (100-240 VAC or 240 HVDC) • 1100 W LVDC -48 - -60 VDC, hot swap redundant |
| Cooling Options | Air cooling / Optional Direct Liquid Cooling (DLC) |
| Fans | Standard (STD) / High performance Silver (HPR) / High performance Gold (VHP) fans; Up to 6 hot plug fans |
| Dimensions | Height: 86.8 mm | Width: 482 mm | Depth: 772.13 mm (with bezel) / 758.29 mm (without bezel) |
| Security | Cryptographically signed firmware, Secure Boot, Secure Erase, Silicon Root of Trust, System Lockdown, TPM 2.0 FIPS |
| Warranty | 3 Years |
The Dell PowerEdge R760 is a 2U, two-socket rack server designed to provide the performance and versatility needed to address your most demanding applications. It is engineered to optimize workloads like Artificial Intelligence (AI) and Machine Learning (ML), making it a full-featured enterprise solution.
As a leading integrated IT solutions provider, we combine cutting edge in-house manufacturing, dedicated R&D facilities, and a robust global distribution network to deliver comprehensive end-to-end infrastructure services. Our team includes more than 150 certified engineers holding top-tier certifications, bringing 15 years of proven expertise in designing, deploying, and maintaining mission-critical IT environments.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
